Pico 1

FEATURES:

  • Full-range mono amplifier 750 Wrms
  • Compact and highly efficient.
  • Ideal complement for PICO series amplifiers, or stand-alone as a universal (subwoofer) amplifier.
  • Mosconi high/low level inputs with switchable load resistors and ground coupling/decoupling

SPECIFICATIONS:

Target Powers
  • 1 x 500 W @ 4 Ohm
  • 1 x 750 W @ 2 Ohm
Input Range
  • 0.3 V ÷ 20 V (LL/HL)
Input Topology High level with switchable dummyload
Low level with switchable ground coupling
Crossover OFF – LP 45 – 310 Hz
HP 13 Hz (Subsonic)
Control Connector for RTC (RTC-2)
Size 150 x 115 x 46mm
